Name:API C Pumping Unit
Type:
Rated polished rod load (lbs):
Stroke (in):
Rated torque of reducers (in.lbs):

Product Description

Brief Introduction
Conventional API C pump units with walking beams, balanced by cranks, are among the most common and most widely used power units in rod production on oil fields.Products comply with Specifications of Pumping Units (API Spec 11E) and other related standards, and have acquired the authorization to use Official API Monogram.
Technical Performance & Characteristics
1.Modular and virtual manufacturing technologies are adopted in design, so that the structure of products is optimized and components are highly standardized, generalized and seriated.
2.Key structural elements are subject to finite element analysis to ensure stable performance and high reliability.
3.Reducers are driven by double-arc symmetrical split or involute herringbone wheels that are properly sealed and distinguished with low noise, smooth operation, reliable and durable service.
4.The entire machine features simple operation and maintenance and extended service life.

Technical Parameters

Model

Rated polished rod load (lbs)

Stroke (in)

Rated torque of reducers (in.lbs)

C-1824D-427-240

42,700

240212196160

1824,000

C-1280D-365-240

36,500

240212196160

1280,000

C-1280D-305-240

30,500

240212196160

1280,000

C-912D-470-240

47,000

240、212、196、160

912,000

C-912D-427-216

42,700

216、185、155

912,000

C-912D-427-192

42,700

192、165、138

912,000

C-912D-305-192

30,500

192、165、138

912,000

C-912D-365-168

36,500

168、144、121

912,000

C-912D-305-168

30,500

168、144、121

912,000

C-912D-427-144

42,700

144、123、102

912,000

C-640D-305-192

30,500

192、165、138

640,000

C-640D-305-168

30,500

168、144、121

640,000

C-640D-365-144

36,500

144、123、102

640,000

C-640D-305-144

30,500

144、123、102

640,000

C-640D-256-144

25,600

144、123、102

640,000

C-640D-305-120

30,500

120、102、84

640,000

C-456D-305-168

30,500

168、144、121

57,000

C-456D-305-144

30,500

144、123、102

40,000

C-456D-256-144

25,600

144、123、102

57,000

C-456D-365-120

36,500

120、102、84

40,000

C-456D-305-120

30,500

120、102、84

25,000

C-456D-256-120

25,600

120、102、84

25,000

C-320D-256-144

25,600

144、123、102

320,000

C-320D-256-120

25,600

120、102、84

320,000

C-320D-213-120

21,300

120、102、84

320,000

C-320D-305-100

30,500

100、85、70

320,000

C-320D-256-100

25,600

100、85、70

320,000

C-320D-213-86

21,300

86、71、56

320,000

C-228D-213-120

21,300

120、102、84

228,000

C-228D-173-100

17,300

100、86、72

228,000

C-228D-246-86

24,600

86、71、56

228,000

C-228D-213-86

21,300

86、71、56

228,000

C-228D-200-74

20,000

74、64、54

228,000

C-228D-173-74

17,300

74、64、54

228,000
