Name:Rig RT70LD
Nominal Druilling Depth:4500~7000
Max. Hook Load,kN:4500
Drawworks Power,kW:1470
Mud Pump Power,kW:3×1176
Mast Type:K/Kc
Mast Clear Height, m:45
Substructure Type:Box Type/ Swing-lift Front Section
Substructure Dril Floor Height, m:9
Substructure Clear Height, m:7.6
Drive Mode:AC-DC-AC /AC-SCR-DC
Power Package,kW:4×810

Product Description

The rotary table is driven by DC or AC VFD motor and the drawwoks and mud pump are driven by disel engine, which costs less than electric drive rigs and eliminates the long distance transmission and high-position rotary drive of mechanical drive rigs.

A significant difference between this type of rig and fully mechanical drive rig is that the ratary table is independently driven by electric motor, which enhances the procision of drilling operation and the quality of the well.

Rig model

RT40LD

RT50LDB

RT70LD

Nominal Druilling Depth

127mm(5") Drill Pipe

2000~3200

2800~4500

4000~6000

114mm(4 1/2") Drill Pipe

2500~4000

3500~5000

4500~7000

Max. Hook Load,kN

2250

3150

4500

Drawworks Power,kW

735

1100

1470

Mud Pump Power,kW

2×956

2×1176

3×1176

Rotary Table

ZP275

ZP375

ZP375

Mast

Type

K/Kc

K/Kc

K/Kc

Clear Height,m

43/44

45

45

Substructure

Type

Box Type

Box Type/ Swing-lift  Front Section

Drill Floor Height,m

6/7.5

7.5/9

9

Clear Height,m

4.8/6.3

6.3/7.6

7.6

Drive Mode

AC-DC-AC /AC-SCR-DC

Power Package,kW

3×810

3×810

4×810
