Name:Rotary Table
Opening diameter (mm):
Rated dead load(kn):
Max. torque (kN.m):
Distance from the central line of rotary Table to the central line of row teeth within chain wheel (mm):
speed ratio of gears:
Max. rotary speed (r/min):
Overall Dimension(mm):
Weight (kg):

Product Description

Rotary table design characteristics with Big and small gear are alloy steel materials. Low overall master bushing for steel casting.Low pin drive type can be put into the API standard kelly or six kelly roller bushing, long and short slip all can use.

Low wheel lubrication, sealing is reliable.Low rotary table in accordance with API Spec 7 k specification, allows you to use APl emblem.


Model
ZP175
ZP520
ZP275
ZP375
Opening diameter (mm)
444.5
520.7
698.5
952.5
Rated dead load(kn)
2700
3150
4500
5850
Max. torque (kN.m)
13.7
22.6
27.5
32.4
Distance from the central line of rotary Table to the central line of row teeth within chain wheel (mm)
1118
1353
1353
1353
speed ratio of gears
3.58
3.62
3.67
3.56
Max. rotary speed (r/min)
300
300
300
300
Overall Dimension(mm)
1972×1372
×566
2266×1475
×704
2380×1670
×685
2415×1810
×718
Weight (kg)
4172
5862
6122
7970
